CASA GZ

Design Team:

Gabriel Cáceres, Daniel Lazo.

Collaborators:

Alejandra Sepulveda, John Miller.

Location:

Santiago de Chile / Chile

Total Area:

11000 m2

Built Area:

280 m2

Project Year:

2014

Materials:

Concrete, steel, glass, fibercement boards.

Renders:

SCL

Photography:

Pablo Casals Aguirre

Description

At the beginning of 2012 a young couple approached our practice for a house. They had fallen in love with the beautiful setting of a small community on the outskirts of Santiago. On top of a steep hill, no road to reach it, with all the utilities’ network down below, the plot posed quite a challenge. Amazing unobstructed views of the Chicureo valley, however, made it more than worth the effort. The clients were in no rush for the house to be built, so for a time the project was halted for them to put together the money for construction. In the meanwhile, we were tasked with figuring out how to build a road on the hill without either destroying it or bankrupting the client.

Two years later the road was done and the pieces in place for the project to resume. By then, the couple already had their first child and was expecting their second. The program increase forced us to scrap any previous schemes we had fiddled with and start over. The time lost however allowed us to get to know the couple much better, so by the end of the design phase the final project was tailor-made for them in a way that otherwise wouldn’t be possible. Reasonably, the view of the landscape became the house’s raison d'etre. A room without a view -no matter its purpose- was unacceptable. Also, because they had been living in an apartment for quite a while they felt very strongly that everything should fit onto a single floor.

A chain-like sequence of rooms became the logical layout for the house, where all of the common areas sit at the center of the chain with the couple’s master bedroom at one end and the children’s and guest rooms at the other. This gives the parents a certain level of independence once the children are older. Next to the kitchen a covered terrace was added to allow for the husband’s preference for grilling –no matter the season or weather.

The clients wanted a beach house feel for their home. An interesting request design-wise. As we saw it, the main difference between a holiday home and a regular one is lack of definition in the program’s boundaries. To address this idea, the design was to deliberately avoid creating one-purpose-only spaces, like corridors. Ironically, because of the nature of the chain-link layout, a corridor was actually needed to connect each space without having to resort to a Versailles-style series of connecting rooms. The needed corridor was then broken, displaced and distorted, for the pieces not to resemble a corridor and allow other uses than the obvious one. One piece became the entrance hall/gallery space -almost 5 meters tall and lit from the sky - that showcases the client’s incipient art collection. The other, not as tall but twice as wide, became the children’s play/study room. A small patio separates both. Living, kitchen and dining rooms are all integrated into a single space, enclosed by large windows at two sides. Both sides slide back to expand the fun to the adjacent covered, outdoor terraces when desired. Boundaries were also blurred at the master bedroom, with just a big walk-in closet dividing it from the bathroom, no doors whatsoever.

Atop a set of boulders protruding from the hill at mid-height, the long and narrow chain-link scheme creates a gravity-defying image. Both ends cantilevering freely, it seems like a balancing act. Despite the effect, the house’s concrete slab rests safely over a podium defined by retaining walls of the same material. Slim, slanted columns were added wherever extra support was needed. Their irregular shape and inclination exaggerate the sensation of instability. Outside, Equitone© fiber-cement boards were used to clad the whole of the steel structure that arises from the slab and shapes the house. An air chamber between this skin and the house’s inner envelope is placed to help with its thermal comfort. Because of its color, the cladding and concrete give the house a monolithic appearance, only subverted by the glass façade that faces the panorama. This controlled material palette makes the house a constant monochromatic counterpoint to the extreme changes in color and vegetation that the site undergoes through the seasons –from desert-like shades of browns and yellows in the summer to the most exuberant greens during the winter.

Four years after their call, the now full-blown family of four finally moved to their tailor-made house on a hill. Happily, they found it to be a comfortable fit.

DSP APARTMENT BUILDING

Design Team:

Gabriel Cáceres, Daniel Lazo.

Collaborators:

John Miller, Tomislav Mímica.

Location:

Santiago de Chile / Chile

Built Area:

385 m2

Project Year:

2018-2019

Materials:

Precast concrete, steel, glass, expanded aluminum mesh.

Model:

Nicolas Allende

Renderings:

Ken Qiu

Photography:

Daniel Lazo

Description

The city of Santiago like many other capitals of the developing world is going through a fast-paced urban transformation process. Long-neglected parts of the city have seen a dramatic surge in real estate development and construction over the last 20 years. The city’s downtown neighborhoods have been affected like no other. Mostly abandoned to economic and institutional roles during the eighties, the new century has brought a steady, exponential repopulation process. Along with the positive outcomes—like the reappreciation of public space and urban life—rising real estate prices and rents are making it increasingly difficult for the new urbanites to find housing, while predatory urban development practices threaten to erase the very character that brought them to these neighborhoods in the first place.

The Ochoalcubo DSP project proposes a sustainable way for housing development. Fitted in a lot previously occupied by just one residence, it’s an exercise in micro-scale density. Three different apartment typologies are housed inside a precast concrete shell: a 1730-square-foot duplex apartment on the ground floor with a large backyard; a 700-square-foot studio apartment on the second floor; and a 1400-square-foot penthouse at the top that enjoys the whole rooftop. At the center of the building, an ethereal steel-plate staircase, painted bright cerulean, provides access.

The building structure is basically a shelf that spans the width of the property, built with precast walls and a double-tee flooring system, traditionally used for multi-story parking garages given the long spans it achieves without the need for central support. This single quality allows for the multiplicity of types inside the building, making each floor’s interior effectively independent from the one below. An expanded aluminum veil covers front and back facades providing both shade and privacy from the street.

FINTUAL HEADQUARTERS

Design Team:

Gabriel Cáceres, Daniel Lazo.

Collaborators:

John Miller, Tomislav Mímica, Diego Melero.

Location:

Santiago de Chile / Chile

Built Area:

500 m2

Project Year:

2020

Materials:

Stainless steel, glass, laminated wood panels.

Photography:

Bruno Giliberto

Description

Over the last decade, Chile’s startup scene has positioned itself as one of the leaders of the region. Ambitious government programs mixed with a booming generation of young innovators has turned the small South American country into an internationally renowned hub for emergent tech entrepreneurs, reaping an important number of interesting and successful technological products. Fintual is one of those groups of entrepreneurs—founded in 2016 and live since 2018—their goal is to bridge the gap between financial investment tools and the general non-savvy public, by way of technology and a candid and straightforward strategy of communication with their clients, sprinkled with a healthy dose of humor. As of 2020, they manage funds for 47 thousand clients at more than 425 million USD—a big jump from the 7 thousand clients and 44 million of the year before, which meant they needed more people on their team and eventually a bigger space.

The Droguett Palace has lived many lives. An urban residence for a wealthy family built in 1931 by famous architect Sergio Larraín García-Moreno, the 12-bedroom, 1400 sqm building became one of the city’s staples in the early 80’s when the family heirs transformed it into an event venue. It was at this time that its huge (300 sqm) 2nd floor outdoor terrace was covered with the glass and steel barrel vault that would give it its characteristic look and earn it the moniker “The Glass House”.

In 2011 the venue closed its doors and started a new life as an office and coworking hub for innovation and entrepreneurship, first for a global conglomerate and later for StartUp Chile, the country’s government-run startup accelerator program.

In late August of 2020, in the midst of the global pandemic, just as the city of Santiago was coming out of a 4-month-long lockdown, we were commissioned—through a brief private competition—to design the headquarters of Fintual at the Droguett Palace, which they had just leased. The brief was straightforward. The project would be developed in stages, with the first one being the main office floor located on the building’s second level. Needing to accommodate 40 to 60 employees at all times, the project was to provide multiple ways of working, from conventional desk work to hot desking, private and group conference calls, as well as more laid-back living room and coffee shop type situations. It had to be a fun space to work in and it should reflect the horizontal culture of the company. And they wanted plants. Lots of them.

There was one caveat, though. They needed to move in fast.

The general scheme for this first stage was developed in 10 days—during the competition phase—and concentrated primarily on the former outdoor terrace now covered with the barrel vault of glass, or “pergola” as Fintual calls it, since the interior of the palace needed less of an intervention and more of a furnishing because of its already superb spatial qualities.

The plan for the pergola was simple: replicate the order established above by the barrel vault, down below. The rectangular cross section of the vault would then divide the space into two main areas, one for the working stations and the other—irregularly shaped—allowing different types of work situations. For this, we developed a series of objects, all familiar between each other and named according to what they looked like or their function (a snaking desk is “the worm”, while the private pods are “the booths”, for example). Except for the desks (fabricated in matte white) all the elements shared the same materiality: laminated wood boards.

Working within a tight building budget, it was established early on with the client that we were looking for a low cost but elegant aesthetic, balancing the cheap with more expensive accents, or “like wearing a worn-out T-shirt with some expensive jeans” as Pedro, one of the company’s founders, once told us. The wood provides a good example of this approach, while not the cheapest wood available, it has a nice warm color and is free of knots , giving the furniture a more homogeneous and abstract look, like a solid piece, while on close inspection the on-site fabrication would reveal slight imperfections and a certain rustic quality.

The whole space would be painted anthracite black, to cancel all the visual noise produced by utilities networks, insulation foam boards, and the array of girders and structures that run through the ceiling, and to make a stark contrast from the chalk white interior of the palace.

The finishing touch was a stroke of luck. At some point in the building’s life the original luxurious white terrazzo tile floor of the terrace was clad with a cheap photo-laminated engineering flooring. But after removing the coverings: there it was, all complete and in decent condition, all it needed was a thorough polish and sealant.

Since Fintual needed to move in quickly and we needed time to develop construction documentation, we divided the construction in two: a wet and dirty phase—meaning all the work that cannot be done with people using the space, including painting the entire second floor and polishing both the terrazzo as well as the beautiful parquet flooring on the palace side—and a clean phase—involving both on-site and off-site fabrication of the furniture and power network, while working around Fintual using the space.

That everybody involved made it work despite strict transit restrictions, lockdowns, curfews, a national shortage of building materials, and of course a global pandemic, seems like an achievement already. But the project is as rewarding by exploring contemporary architectural issues on heritage buildings, and hit-the-ground-running strategies to design, while celebrating the innovative and forward-thinking culture at the core of Fintual.

MAISON A LUXEMBOURG

Design Team:

Gabriel Cáceres, Daniel Lazo.

Collaborators:

John Miller, Tomislav Mímica, Jose Vizcaya, Diego Melero.

Location:

Luxembourg City, Luxembourg.

Built Area:

550 m2

Project Year:

2018-2019

Materials:

Concrete, steel, glass, bronze, marble.

Renderings:

Tomislav Mimica, Jose Vizcaya

GLOBOX PRODUCTION COMPANY HQ

Design Team:

Gabriel Cáceres, Daniel Lazo.

Collaborators:

John Miller, Tomislav Mímica.

Location:

Santiago de Chile / Chile

Built Area:

140 m2

Project Year:

2018

Materials:

Polycarbonate sheets, glass, wood.

Photography:

Felipe Fontecilla

Description

Since the late 90’s, an early 20th century house in downtown Santiago has been home to an important part of Chile’s underground electronic music scene. The “Santo Remedio Bar and Restaurant”, occupying its first floor, it is a venue where renowned local DJ’s have played their first sets, and host to an important list of international stars. When the owner’s production company -responsible for important music festivals across the country- decided to relocate their operations to the second floor of the house, they required for a radical transformation of the former hair saloon space. Multiple precarious conversions had left their mark all across the old adobe-and-timber structure, and it was in a weakened state. Adobe craftmanship has become a lost art, and as such restoration of this kind has become quite expensive. A limited budget and time schedule rendered the possibility of restoring the walls to its original state, a dead end. Striping the adobe from the dividing walls and reinforcing the timber skeleton was needed but budget constraints meant that it was to be done in localized form, leaving the interior walls an unsightly mish-mash between leftovers of the previous conversions (fiber cement, sheet rock and tin panels haphazardly attached) and patches of naked structure.

The project then became the act of sheeting this mess, front and back, with semi-translucent polycarbonate panels, turning the chaotic patchwork of materials into an abstract array of shadows that change depending of the source of the light. During the day, sunlight would give the plastic warmer tones, and LED geometric lines of light would tint it a blue hue at night. The same idea was then repeated for the main office room ceiling by hanging a metal mesh of expanded aluminum, and again for the meeting room with a hanging polycarbonate ceiling below a skylight the whole size of the room. The few divisions of the entire space where handled with aluminum sliding doors, and the galvanized steel pipes of the electrical network where left exposed. For the connecting corridors, a loose spaghetti-like hanging lamp was designed out of LED tubes. To counter this rather cold industrial look, a grainy German oak wood was selected for the flooring, the one and only expensive item of the whole endeavor.

The stark contrast between the brisk irregularity of the adobe walls still exposed, the refined dignity of the oak, and the machine precision of both the translucent plastic and aluminum mesh, do this time make for a more sightly mix of ingredients.

TERMINAL INTERNACIONAL DE PASAJEROS MAGALLANES

Competition Entry

Authors:

TCL Architects.

Design Team:

Daniel Lazo, Albert Tidy.

Collaborators:

Ken Qiu Sun, Loreto Cerda, Cristóbal Riffo.

Location:

Punta Arenas, XII Region de Magallanes / Chile

Built Area:

45000 m2 (Masterplan)

3500 m2 (TIP building)

Project Year:

2017

Materials:

Concrete, steel, glass.

Renders:

Loreto Cerda

EDIFICIO EMILIO PUGÍN FACULTAD DE CIENCIAS UNIVERSIDAD AUSTRAL DE CHILE

Competition / First Prize

Architect:

Tidy Arquitectos

Design Team:

Albert Tidy, Daniel Lazo (as associated architect).

Collaborators:

Nicolas Solis de Ovando, Eduardo Tapia, Victor Bustos, Roberto Jacob, Tom De Soete, Cesar Osorio.

Location:

Valdivia. XIV Region de los Rios / Chile

Built Area:

10620 m2

Project Year:

2009-2012

Materials:

Concrete, glass, steel.

Photography:

Pablo Casals Aguirre

DUPLEX

Design Team:

Gabriel Cáceres, Daniel Lazo.

Collaborators:

John Miller, Tomislav Mímica.

Location:

Santiago de Chile / Chile

Built Area:

90 m2

Project Year:

2017

Materials:

Concrete, stainless steel, glass, wood, microcement flooring.

Photography:

Daniel Lazo

ROMAN DIAZ BUILDING

Design Team:

Gabriel Cáceres, Daniel Lazo.

Collaborators:

John Miller, Tomislav Mímica.

Location:

Santiago de Chile / Chile

Built Area:

15.000 m2

Project Year:

2022

Materials:

Concrete, steel, glass, expanded aluminum mesh.

Renderings:

Tomislav Mimica

2LSD APARTMENT BUILDING

Design Team:

Gabriel Cáceres, Daniel Lazo.

Collaborators:

John Miller, Tomislav Mímica, Diego Melero.

Location:

Santiago de Chile / Chile

Built Area:

385 m2

Project Year:

2021

Materials:

Precast concrete, steel, glass, brick.

Renderings:

Tomislav Mimica

OFICINAS APLAPLAC

Design Team:

Albert Tidy, Gabriel Cáceres, Daniel Lazo (as TCL Architects).

Collaborators:

Sebastián Cruz

Location:

Santiago de Chile / Chile

Total Area:

600 m2

Built Area:

110 m2

Project Year:

2013

Materials:

2x4” pine wood slats, 4 mm. polycarbonate honeycomb sheets, 25mm plywood boards.

Photography:

Pablo Casals Aguirre

Description

As side effect of an important commission for designing a multi program complex in an old hat factory, we were given the opportunity to establish our architecture studio temporarily in what’s perhaps every architect’s dream: a huge old industrial warehouse.

The warehouse -kindly provided to us by the clients of the project, for as long it takes to see it through- possess remarkable qualities in terms of space, sun light and openness. Its precarious thermic conditions, however, made it also uninhabitable.

To solve this issue, we required of an ephemeral and disposable enclosure that allowed us to operate in conditions of comfort and livability, but achieved in a minimum amount of time and as cheap as possible.

The final result is a modest structure of 2” by 4” pine wood slats, completely cladded in translucid 4 mm. thick polycarbonate honeycomb sheets (105 x 290 cms.), including the ceiling. The measurements of every element involved were done considering the commercial dimensions of all materials, reducing the left over loss. In addition, to avoid any interior structural element, we used prefab H beams -manufactured in pine wood and OSB boards- capable of covering the whole span of the structure while supporting the weight of the entire ceiling.

This 8.5 x 8.5 x 2.9 meters box allowed us to reduce the air volume to control, and achieve thermic comfort without much effort. Two “Split” HVAC units keep the entire box at constant 21 degrees Celcius.

After publishing our temporary installations, we were contacted by “Aplaplac Production Company”, creators of the hit children TV show “31 minutos”, entirely played by cloth puppets -in the tradition of Sesame Street- and of a budget inversely proportional to its genius level of creativity.

Till this point in time, the whole production company operation was dispersed and precarious, with their offices located in one place and the storage space in another, while having to rent the recording studio when filming each season of the tv show. In 2013, they finally decided to consolidate each individual element of the program under one roof: a new industrial warehouse located in an old residential neighborhood in downtown Santiago.

Faced with the same challenge we had already encountered, Aplaplac decided to hire us to repeat the same solution, but adapting it to its new requirements. Needless to say, the opportunity to design the offices of puppets stars such as “Tulio Triviño”, “Juanin Juan Harris”, “Bodoque” and “Guaripolo” proved to be impossible to resist.

This time around, the proposal was to repeat the strategy but with three different boxes, varying in sizes to accommodate each individual part of the program. From the warehouse access, the first box contains the administrative and executive offices of the show. The second box and the biggest in size, holds the scriptwriters offices. The third and final box is the show’s workshop, where the puppets are manufactured. The rest of the warehouse´s space -more than half of the total space- remains free for storage use as well as for the recording & filming studio.

The parallelism of the boxes layout is deliberately broken as to create tension and vantage points between them, in reference to works such as the “Metaesquemas” (1958-1959) created by Brazilian artist Helio Oiticica.

The in-between space generated by the layout, creates a relationship between each individual element and the others as well as with the warehouse that contains them. These spaces allow more informal events to happen, like small rooms for leisure.

The entire project was built in 3 days, and the end result left the cast of “31 minutos” happy enough that they insisted in being part of the photo-shoot that we’re now publishing.

FACTORIA ITALIA

Competition / First Prize.

Design Team:

Albert Tidy, Gabriel Cáceres, Daniel Lazo (as TCL Architects).

Collaborators:

Victor Bustos, Tomas Mascaró, Sebastián Provoste, Sebastián Cruz, Gabriel Díaz.

Location:

Santiago de Chile / Chile

Built Area:

37700 m2

Project Year:

2012-2014

Materials:

Concrete, steel, glass, brick.

Renders:

Jorge Silva, Daniel Lazo, Ken Qiu.

DPAV THEATER-RESTAURANT

Design Team:

Gabriel Cáceres, Daniel Lazo.

Collaborators:

Alejandra Sepulveda.

Location:

Santiago de Chile / Chile

Total Area:

860 m2

Built Area:

800 m2

Project Year:

2014

Materials:

Concrete, steel, glass, fibercement boards.

Photography:

Pablo Casals Aguirre

Description

Over the chassis of an early 20th century house a constellation of objects, related in geometry, color and character, is proposed. Their strategic placement –sometimes disruptive to the logic of what already exists- transforms the interior of the house and forces a redefinition of the role of each program component. Removal of adobe cladding from some interior dividing walls amplifies this change, leaving bare the oak structural skeleton and generating new and unexpected visual connections.

The change in use –from residential to cultural, private to public- is evidenced by the scale of the new objects (doors, windows, furniture, lighting fixtures, etc.) that respond to and anticipate this new order, as a reflection of the episodic nature of the events that take place here.

The most dramatic part of the operation is the insertion of a small 200-seat dinner theater in the space previously occupied by a series of small, precarious expansions to the original building. The theater itself is treated as another object: monolithic and introverted from the exterior, just three openings interrupt its envelope. On the contrary, the interior is soft and expressive, courtesy of an acoustic skin manufactured on-site with timber slats of varying sizes and sections.

The house as much as the theater works as a stage for music and dance. Performers move, along with the guests, from the “quincho” –an inner-courtyard redefined by a 6-meter high chimney over a barbecue pit in the center of the space- to a media gallery, and then the dinner theater for the main event.

The end result is an architecture of things, where the new -monochrome and abstract in design- is in constant tension with the historicist architecture of the existing house, in a deliberate game of contrasts.

PROVIDENCIA CITY HALL CAMPUS

Competition Entry /  Honorable Mention.

Authors:

TCL Architects.

Design Team:

Daniel Lazo, Gabriel Cáceres, Albert Tidy.

Collaborators:

Ken Qiu, John Miller, Tomislav Mímica, Sebastián Simonetti.

Location:

Santiago de Chile

Built Area:

12500 m2

Project Year:

2017

Materials:

Concrete, steel, glass.

Renders:

Ken Qiu

Model:

Nicolas Allende

CASA OCHO QUEBRADAS

Design Team:

Gabriel Cáceres, Daniel Lazo

Collaborators:

John Miller

Location:

Los Vilos, IV Region de Coquimbo / Chile

Built Area:

110 m2

Project Year:

2016

Materials:

Prefab Concrete, steel, glass.

Renders:

SCL

Description

Context.

Ochoalcubo, is an exceptional housing development on the coastal town of Los Vilos, designed by 16 internationally renowned architects from Japan and Chile. A second stage named Ochoquebradas has been launched, inviting emergent architecture practices.

Studio CL produced the 3X7 House project for this purpose.

Project.

The 3X7 house is an architectural exercise in economy. Not only in relation to the cost of the project but also, the use of resources and space. The 3X7 house is named after the number of times it repeats the same basic unit to produce it. The unit is a prefabricated reinforced concrete casket, an ordinary, uninteresting element commonly used in infrastructure of all kinds (bridges, canals, etc.). Nevertheless, it boasts a generous interior (an inner section of 3m by 3m and 1.5 m depth). 3 naves, units long, placed side-by-side, make a 110 sqm house. Each nave is divided differently so as to organize the program. While the side naves contain the bedrooms and bathrooms, the central nave houses the public spaces - living, dining, and kitchen - in one integrated continuous space. This nave also connects with each different room. Perforations in the concrete structure, give direct access to each space, eliminating the need for aisles and maximizing the useful floor area of the house. Both floor and the walls exposed to the elements are internally lined to improve thermal comfort, as well as to hide utilities. A concrete rooftop terrace tops the house, adding an extra space while protecting the roof insulation.

MUSEO DE ARTE DE LIMA NEW CONTEMPORARY ART WING

Competition entry

Architects:

Pablo Talhouk Arquitectos Asociados + SCL.

Design Team:

Pablo Talhouk, Andres Briones, Daniel Lazo.

Collaborators:

Erick Marín, Layla Jorquera, Fernando Torres, John Miller.

Location:

Lima, Perú.

Built Area:

6500 m2

Project Year:

2016

Materials:

Concrete, steel, glass.

CENTRO CULTURAL SITIO ESTANQUE

Competition / Third Prize

Design Team:

Albert Tidy, Gabriel Cáceres, Daniel Lazo (as TCL Architects).

Collaborators:

Sebastián Cruz, Victor Bustos, Tomas Mascaró.

Location:

Valparaiso, V Region de Valparaiso / Chile

Built Area:

4500 m2

Project Year:

2013

Materials:

Concrete, steel, glass.

Renders:

Sebastián Cruz

BODEGÓN FERROVIARIO CARAHUE

Competition entry

Design Team:

Gabriel Cáceres, Daniel Lazo

Collaborators:

John Miller

Location:

Carahue, IX Region de la Araucanía / Chile

Built Area:

400 m2

Project Year:

2016

Materials:

Concrete, steel, glass, wood.

Renders:

SCL

TCL ARCHITECTS OFFICE

Design Team:

Albert Tidy, Gabriel Cáceres, Daniel Lazo (as TCL Architects).

Collaborators:

Sebastián Cruz

Location:

Santiago de Chile / Chile

Total Area:

400 m2

Built Area:

80 m2

Project Year:

2013

Materials:

2x4” pine wood slats, 4 mm. polycarbonate honeycomb sheets, 25mm plywood boards.

Photography:

Albert Tidy
